The selection of products manufactured by Zeus Foils are not only of the highest quality but are also available in a variety of options to ensure you find exactly what you’re looking for. With top-of-the-line materials, cutting-edge production technologies and a highly qualified team, we guarantee complete satisfaction.
"One Aluminum mast fits all"
Wingfoil ...
.... or Windfoil
"... Adding a short fuselage and a top adapter we can have both ..
Windfoil and Wingfoil (on 1150cm2 setup) .... "
1150cm2
1350 .. 1700cm2
" Customized front Wing Area !!!! "
1150cm2
840cm2
840/1150cm2
The "LWing"
Our lightwind machine ... The "Lwing".
The "Lwing" is a wing "embedded" on the mast of the foil and helps the whole system to "take off" (earlier than a conventional foil) when the wind is low ( from 5 .. 6 kts).
No need pumping !! ( Additional pumping helps more !!! )
The embedded wing in combination with the main front wing produces the required lift for early planning and take off.
When the system reaches a high point , the rider starts foiling firstly with the gravity without the contribution of the embedded wing. When reaches a speed above critical (meaning ... above "the stalling speed") can continue to foil on a normal way.
During foiling the embedded wing does not contributes . It is out of the water !!!
It is so cool !!! Try it !!
(Jibing : During the jibe , the system can be easily controllable even if the embedded wing dives below the sea level. )
(For best results , the mast need to be more than 80 .. 85cm . (Our Aluminum mast : 88cm))
"..Coming soon .."
WINDSURF FOIL
At our company we pride ourselves
on exceptional quality.
From the initial concept to the final product , our attention to detail is second to none , In an ever-evolving industry,
ZeusFoils has set the standard for innovation and delivery.
Explore our site and see for yourself - we love our work and we’re sure you will, too.
The "LWing" , "L-Foil"
WINDFOIL PRODUCTS
In Stock. 2-3 days delivery
FLY_V2
The perfect windfoil for freeriding with earlyplanning for endless foiling
Mast : Aluminum , 880mm height
Front Wing Span/Area/AR : 900 mm / 840cm2 / AR = 9.64
Material : Prepreg Carbon
Back Wing Span/Area : 500 mm / 300 cm2
(alternative : 450mm / 250cm2)
Material : Prepreg Carbon
Fuselage : 958mm length ,
material : Aluminum 6061 T6
anodized
In Stock. 2- 3 days delivery
FLY_V2_(with two wings)
The perfect windfoil for freeriding with earlyplanning for endless foiling
Mast : Aluminum , 880mm height
Front Wing1 Span/Area/AR : 900 mm / 840cm2 / AR = 9.64
Material : Prepreg Carbon
Front Wing2 Span/Area/AR : 900 mm / 1150cm2
AR = 7.04
Material : Aluminum Anodized
Back Wing Span/Area : 500 mm / 300 cm2
(alternative : 450mm / 250cm2)
Material : Prepreg Carbon
Fuselage : 958mm length ,
material : Aluminum 6061 T6
Limited Stock. 2-3 days delivery
FREERACE - FREERIDE
FR900_PRO
Combines the free-racing ability with minimum drag and superior lift.
Mast : Prepreg Carbon Fibers , 950mm height
Front Wing Span/Area/AR : 900 mm / 840cm2 / AR = 9.64
Material : Prepreg Carbon
Back Wing Span/Area : 450 mm / 250 cm2
Material : Prepreg Carbon
Fuselage : 1100mm length ,
material : Aluminum 6061 T6 , anodized
In Stock. 2-3 days delivery
FREERACE - FREERIDE
FR900
Combines the free-racing ability with minimum drag and superior lift.
Mast : Prepreg Carbon Fibers , 950mm height
Front Wing Span/Area/AR : 900 mm / 840cm2 / AR = 9.64
Material : Prepreg Carbon
Back Wing Span/Area : 450 mm / 250 cm2
Material : Prepreg Carbon
Fuselage : 1080mm length ,
material : Aluminum 6061 T6 , anodized
FR900 ALU MAST
In Stock. 2-3 days delivery
FR900 ALU MAST
Free-race ability with a more affordable cost approach .
Mast : Aluminum anodized , 880mm height
Front Wing Span/Area/AR : 900 mm / 840cm2 /AR 9.64
Material : Prepreg Carbon
Back Wing Span/Area : 450 mm / 250 cm2
Material : Prepreg Carbon
Fuselage : 1080mm length ,
material : Aluminum 6061 T6 , anodized
In Stock. 2-3 days delivery
BEGGINERS - INTERMEDIATES - FREERIDE
FLY
It is the product that suits to all kind of riders . From the beginner to the more experienced one.
Mast : Aluminum anodized , 880mm height
Front Wing Span/Area/AR : 900 mm /1150cm2/AR 7.04
Material : Anodized Aluminum
Back Wing Span/Area : 500 mm / 300 cm2
Material : Prepreg Carbon
Fuselage : 958mm length ,
material : Aluminum 6061 T6 , anodized
Options for head : (see "manual menus")
(for models FLY and ALU mast)
1. Deep Tuttle box with nose shim *
2. Deep Tuttle box (or tuttle) with flange *
* : The strength/rigidity of windsurf board boxes on owner's responsibility
Front Back WING FR900
In Stock. 4-5 days delivery
Front wing FR900 ( prepreg CF)
Length : 90 cm
Area : 840 cm2
AR = 9.64
Back WING FR900
In Stock. 4-5 days delivery
Back wing FR900 ( prepreg CF)
Length : 45 cm
Width : 7.2 cm
Area : 250 cm2
The wings are not painted
All the prices are subject to change without notice
This hydrofoil mast has great bending and “torsional stiffness” characteristics, since on foiling it is very critical to have a very “rigid” straight line without feeling any flexibility underneath
the board.
